Ultrasonic flow sensors / flow meters are widely used across various industries for fluid measurement. However, certain specialized applications require the use of non-invasive ultrasonic flowmeters, particularly in measuring cleaning and cooling water in PCB production equipment and lithium battery manufacturing.

1. Precise Cleaning and Cooling Water Flow Measurement

Battery manufacturing and industrial devices rely heavily on various types of water, cooling water, purified water, ultra-pure water, and more, for cleaning and thermal management. Some fluids are non-conductive, ultra-pure water, while others may carry corrosive chemicals like hydrofluoric acid. This diversity demands exact flow measurement and stringent control to optimize resource usage and maintain product quality

The flowmeters used in such environments must meet key requirements

1)High repeatability and reliability even under aggressive chemical exposure

2)Quick, flexible, and clamp-on installation to avoid production downtime

3)Strong corrosion resistance to safeguard sensor electronics against harsh liquids

文章内容 — CPD series clamp-on ultrasonic flow sensor

XY-TEK CPD Series Clamp-On Ultrasonic Flowmeter

It can be clamped externally onto the tubing without cutting the tubing for installation. This eliminates any risk of fluid contamination or sensor fouling. Its durable design withstands corrosive environments, ensuring long-term, reliable performance in demanding industrial workflows.

2. Accurate Flow Measurement for Small-Diameter Tubing and Viscous Liquids

Small-diameter tubing is common in industrial and electrical manufacturing equipment, especially when handling viscous fluids such as lubricating oils and glues.

However, precise flow measurement in such applications is technologically challenging and often met with limited, costly options on the market

The CPD Series Clamp-On Ultrasonic Flowmeter is ideal for small tubing flow measurements

1)Supports measurement of tubing as small as 6.4 mm OD (outer diameter) #PFA #PU

2)Resistant to acids, bases, hydrochloric acid, and a wide range of organic solvents

3)Meets international accuracy standards, providing trustworthy readings for vital process control

3. Flexible Signal Output and Seamless Integration

To support versatile system integration, the CPD series offers multiple communication interfaces. The standard RS-485 protocol ensures easy connection to local control networks and remote monitoring setups.

Moreover, XY-TEK can customize communication protocols to fit specific client requirements, enhancing compatibility and streamlining data flow.
