CS series Clamp-on Ultrasonic Flow Sensor / Flow Meter

The CS series clamp-on ultrasonic flow sensors / flow meters are compact, enabling efficient flow measurement and air bubble detection output without external circuitry.

It is designed for rigid plastic tubing materials such as PFA, PTFE, Teflon, PVDF, PP, and Nylon.

It provides non-invasive measurement of flow rates with high accuracy and stability and can be reused multiple times without disinfection, eliminating the risk of cross-contamination.

The CS series comes with different sizes to accommodate various tubing diameters and can be configured for flow switching, and dosing control functionalities.

Product Features

High Accuracy:±3%

The flow rate measurement accuracy is essential for applications requiring stringent quality control and process optimization.

Hygienic Safety

The non-invasive measurement reduces the contamination risk and makes it ideal for sensitive applications in the pharmaceutical industries, ensuring safety and compliance with health regulations.

Bi-Directional Flow Measurement

Support accurately calculating fluid volume and detecting air bubbles. Additionally, it can perform volume dosing and function as a flow switch, providing a multifunctional solution that enhances operational versatility.

Compact Design

The embedded circuit eliminates external wiring, streamlining installation and reducing space requirements. This design simplifies setup while maintaining high performance.

No Blockages

Designed to operate without blockage or dead zones, enables smoother fluid flow and reduces potential system strain.

Output

CG series ultrasonic flow sensor/flow meters offers multi-output methods that facilitate seamless integration with existing systems.

Product Selection

Part #
Max Flow
Accuracy
Tubing OD
Tubing ID
  • CS025NB
    6000 mL/min
    0-300mL/min: ±9mL/min 300-6000mL/min: ±2%
    1/4" (6.4mm)
    1/8" (3.2mm)
    3/16" (4.8mm)
  • CS031NB
    8000 mL/min
    0-400mL/min: ±12mL/min 400-8000mL/min: ±2%
    5/16" (7.9mm)
    3/16” (4.8mm)
    1/4" (6.4mm)
  • CS038NB
    8000 mL/min
    0-600mL/min: ±18mL/min 600-8000mL/min: ±2%
    3/8" (9.5mm)
    1/4" (6.4mm)
    5/16” (7.9mm)
  • CS050NB
    10000 mL/min
    0-1000mL/min: ±30mL/min 1000-10000mL/min: ±2%
    1/2" (12.7mm)
    3/8" (9.5mm)
    7/16"(11.1mm)
  • CS063NB
    15000 mL/min
    0-1400mL/min: ±42mL/min 1400-15000mL/min: ±2%
    5/8" (15.9mm)
    7/16"(11.1mm)
    1/2" (12.7mm)
  • CS075NB
    18000 mL/min
    0-1600mL/min: ±48mL/min 1600-18000mL/min: ±2%
    3/4" (19.1mm)
    1/2" (12.7mm)
    5/8” (15.9mm)
  • CS100NB
    24000 mL/min
    0-2400mL/min: ±72mL/min 2400-24000mL/min: ±2%
    1" (25.4mm)
    5/8" (15.9mm)
    3/4” (19.1mm)

Specifications

Liquid
Water, blood, drinks, oil, paint, etc, without or not many solid particles
Accuracy
2% plus zero offset
Calibration
Default:22±3 °C, water
Tubing material
PFA, PTFE, Teflon, PP, PVDF, Nylon, etc., smooth inner and outer surfaces
Housing material
Plastic
Input voltage
12-30 VDC
Current
Less than 20mA (no external load)
Connector
8-pin push-pull plug
Fluid temperature
0°C to 60°C
Storage temperature
-20°C to 70°C
Shielding
Grounded
Input and output
  • • RS485 output
  • • Analog output: current output 4-20mA, 0-20mA, 0-24mA, voltage output 0-5V, 0-10V
  • • Frequency output: 0-20KHz
  • • Digital output: NPN, PNP, PUSH-PULL
  • • Digital input: Ground, lasts at least 20ms
Accessory
8-wire shielded cable, default length 1.5m
Optional accessories
  • • USB Data Converter: can connect a sensor to a PC
  • • Flow Sensor Tool Box with display: can connect up to 3 sensors to a PC
  • • Flow Sensor Monitor: can connect to a sensor with a display, and extend the sensor cable out
  • • Flow Sensor Data Cable, 3 meters, push-pull plugs at both ends, can connect the flow sensor monitor and the sensor
